What do HEPA filters, pump gaskets, and window seals have in common? Each depends on foam doing more than one job at once: filtering particulate while managing airflow, holding a compression seal while resisting chemicals and vibration, or keeping moisture out while flexing with the movement of a building.
For 50 years, we’ve helped engineers match foam to that full range of demands and more. Here’s a look at six of our most popular materials and where each performs best in industrial and OEM applications.
1. Beaded Expanded Polyethylene (EPE) Foam
EPE, short for expanded polyethylene foam, is a lightweight beaded foam widely used in industrial applications. It’s made from LLDPE polyethylene resin that’s expanded into beads and block molded into planks under heat and pressure. The result is a closed-cell, isotropic structure with excellent repetitive cushioning and impact resistance in every direction. EPE foam can be fabricated into custom foam parts for OEM manufacturers at our state-of-the-art in-house facilities.
Strengths:
• Impact resistance: Excellent shock absorption for repetitive dynamic cushioning.
• Sustainability: Non-crosslinked, 100% recyclable, and re-meltable back to base resin.
• Class A protection: A two-decade track record protecting high-gloss painted parts, chrome, glass, and powder-coated components.
• Dimensional stability: About 3x more stable at higher temperatures than other closed-cell foams, and roughly 40% lighter than equivalent products.
• Chemical resistance and thermal insulation: Resists hundreds of chemicals and provides about 4R per inch of thermal insulation for cold chain applications.
Drawbacks: Uncovered EPE can degrade under long-term UV exposure. It’s generally less durable than high-density XLPE, and as a bead foam, it can show small gaps between beads on a cut surface.
Industrial Uses:
• Cushion packaging: Protecting high-value products like electronics, sensors and optics, glass, and medical instruments during shipping and long-term storage.
• Automotive: High-gloss painted interior and exterior trim components.
• Medical: Packaging for sensitive and expensive medical devices and equipment.
• Military: Containerization of sensitive parts, blocking and bracing dunnage, and case inserts, certified to CID-A-A-59136, CID-A-A-59135, and PPP-1752D standards.
2. Cross-Linked Polyethylene (XLPE) Foam
XLPE foam is a versatile, resilient closed-cell foam. It’s known for its durability, excellent thermal insulation, and water-resistant properties. That performance, adaptability, and cushioning capability make it widely used across industries.
Strengths:
• Range of densities: Available across a wide range to fit specific applications.
• Thermal and acoustic insulation: Excellent insulation from its closed-cell structure.
• Water and chemical resistance: High resistance to moisture, chemicals, oils, and solvents.
• Flexibility and durability: Highly flexible with strong shock absorption, and resistant to UV radiation.
• Versatility: Lightweight, strong, and readily fabricated into custom shapes and sizes.
Drawbacks: XLPE costs more than non-cross-linked polyethylene foams due to the extra processing, and it doesn’t perform as well as some specialized materials in extremely high-temperature environments.
Industrial Uses:
• Construction: Thermal insulation for pipes, ductwork, and building insulation, as well as soundproofing.
• Automotive: Gaskets, seals, and cushioning components.
• Packaging: Custom-molded inserts for delicate, high-value items, including electronics that need anti-static protection.
• Medical: Orthopedic supports, braces, and medical devices.
3. Expanded Polypropylene (EPP) Foam
EPP, an expanded polypropylene foam, is a beaded foam made from polypropylene, a thermoplastic known for strong mechanical properties and chemical resistance. It’s expanded and molded under heat and pressure into a lightweight, resilient, closed-cell material. EPP is best known for absorbing energy, managing temperature, and standing up to heavy loads and impacts.
Strengths:
• Lightweight: Valuable anywhere weight reduction matters, including the auto industry and aerospace applications.
• Durability: Withstands repeated impacts without losing shape or performance.
• Thermal and chemical resistance: Strong insulation and resistance to oils and solvents.
• Sustainability: Recyclable and re-processable multiple times without significant performance loss.
Drawbacks: EPP costs more than some other foams, like EPS foam, due to its more involved manufacturing process, and can degrade under prolonged UV exposure unless protected or treated for outdoor use.
Industrial Uses:
• Automotive: Impact protection in bumper cores, door panels, and headrests, plus noise reduction in HVAC components.
• Protective packaging: Shock absorption and cushioning for delicate, high-value items.
• Construction: Thermal insulation panels for energy efficiency and temperature control.
• Sports and leisure: Helmets, protective gear, and martial arts mats.
4. Polyethylene (PE) Foam
PE earns its title as the workhorse of industrial foam materials. It’s a durable, lightweight closed-cell foam manufactured through extrusion. Polyethylene resin, a member of the polyolefin resin family, is melted and mixed with a blowing agent that creates gas bubbles as the resin cools and solidifies. Additives introduced during that process create anti-static and fire-retardant variants. PE is also manufactured into related grades like EPE and XLPE.
Strengths:
• Range of densities: from standard grades up to high-density foam.
• Resilience: High impact resistance, good tear resistance, and strong shock absorption.
• Thermal and chemical resistance: Effective insulation and resistance to chemicals, oils, and solvents.
• Moisture resistance: Resists hydrolysis, mold, and mildew, and floats easily.
• Fabrication compatibility: Works well as a cushioning material with consistent foam structures, compatible with CNC machines and foam fabrication techniques like kiss cutting.
• Specialty grades: Anti-static foam, fire-resistant foams, and military specification grades are available, with flammability rating options to meet standards like UL94.
Drawbacks: PE foam offers low soundproofing, limited UV resistance in high-sunlight environments, and reduced flexibility in thicker formulations.
Industrial Uses:
• Packaging: Protective packaging for electronics, appliances, and delicate items.
• Construction: Insulation boards, expansion joint fillers, and sealants.
• Automotive: Interior padding, gaskets, and sound dampening materials.
• Marine: Buoyancy aids and flotation components.
5. Polyurethane (PU) Foam
PU foam is a polymer formed by the reaction between polyols and diisocyanates. It’s valued for its cushioning, insulation, and structural properties across a wide range of industrial applications.
Strengths:
• Range of densities: From soft and cushioning to rigid foam, including rigid polyurethanes for construction foams and structural applications, along with High Resilience Foam (HR foam) for seating.
• Resilience and comfort: Returns to shape after compression, with excellent cushioning and a strong strength-to-weight ratio.
• Thermal and chemical resistance: Strong insulation and resistance to many solvents, though susceptibility varies by formulation.
• Specialty variants: Viscoelastic foams add slower-recovery padding; reticulated foam suits filtration; convoluted foam’s egg-crate profile aids cushioning and sound dampening.
Drawbacks: PU foam costs more than other foams, is sensitive to UV light, and requires added flame retardants to meet flammability rating standards like UL 94.
Industrial Uses:
• Automotive: Seating structures, headrests, armrests, and insulation.
• Construction: Insulation panels, sealants, and adhesives.
• Electronics: Foam inserts for component protection and thermal management.
• Aerospace: Lightweight, high strength components and insulation.
• Appliance manufacturing: Insulating layers in refrigerators and freezers.
• Marine: Protective pads and anti-vibration pads.
Ester vs. ether PU foam: Ester foam runs higher density, resists abrasion and hydrocarbons well, but is prone to degrading in humid conditions. Ether foam, a flexible foam by comparison, runs lower density for greater softness and holds up better against water and most solvents.
6. Neoprene Foam
Neoprene foam, also known as polychloroprene foam, is a synthetic rubber elastomer valued for its durability, flexibility, and resistance to environmental factors. It’s widely used for cushioning and insulation, as well as a reliable, impermeable gasket material. It’s made from chloroprene, a monomer that is polymerized into polychloroprene. Introducing gas during that polymerization process creates a closed-cell foam structure, which is then cured and cut into shapes for different applications.
Strengths:
• Flexibility and resilience: Maintains its properties across a wide temperature range, forms an airtight seal, and offers excellent compression set resistance and tear resistance.
• Thermal and chemical resistance: Insulates against heat and cold, resists flames, oils, solvents, and many other chemicals.
• Water resistance and weather durability: Strong buoyancy and resistance to sunlight, ozone, and weather exposure.
• Vibration dampening: Reduces noise, vibration, and harshness (NVH) in equipment.
Drawbacks: Neoprene costs more than some other foams, isn’t resistant to oxidizing acids, and isn’t recommended for electrical applications.
Industrial Uses:
• Marine: Wetsuits, buoyancy aids, and marine insulation.
• Automotive: Gaskets, seals, and padding.
• Sports equipment: Protective gear, mats, and grips.
• Industrial: Custom gaskets, seals, and cushioning materials.
Choosing the Right Foam for Your Application
Getting the right match requires looking at the load or impact profile, the operating environment, and the fabrication techniques used to turn raw material into a finished part. Our team delivers custom foam solutions from protective packaging to subassembly, kitting, and final assembly.
